Equipment Specs

UTILITY & SPECIFICATIONS

WALL MOUNT WASH

BAY DIMENSIONS

FREE STANDING FRAME WASH BAY

DIMENSTIONS & SPECIFICATIONS

UTILITY

REQUIREMENTS

WALL MOUNT

Wall Mount Wash Bay Dimensions

HOW TO MEASURE:

Minimum dimensions are from nearest inside obstructions entrance to exit

e.g., door tracks, counterweights, etc. Add in additional length for these items.

OPTIONS PREFFERED MINIMUM MAXIMUM
HEIGHT 14’ 0” – 16’ 9” (4267 – 5105 mm) Bay Widths 12’ 4” (3759 mm) 11’ 0” (3353 mm) N/A
HEIGHT 16’ 9” – 18’ 0” (5105 – 5486 mm) Bay widths 12’ 4” (3759 mm) 11’ 8” (3356 mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
WIDTH 27’ 4” Rails (8331mm) (Standard) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
WIDTH 30’ 4” Rails (9246mm) (OBD) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
WIDTH 25’ 4” Rails (7722mm) (Optional) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
OPTIONS PREFFERED MINIMUM MAXIMUM
LENGTH 25’ 4” Rails (7722mm) (Optional) 28’ (8534mm) 25’ 8” (7823mm) N/A
LENGTH 27’ 4” Rails (8331mm) No Dryer 30’ (9144mm) 27’ 8” (8432mm) N/A
LENGTH 27’ 4” Rails (8331mm) Razor and Dryer w/Covers 42’ (12802mm) 31’ 4” (9550mm) N/A
LENGTH 30’ 4” Rails w/On-Board Dryer (9246mm) 42’ (12802mm) 31’ 4” (9550mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
HEIGHT 14’ 0” – 16’ 9” (4267 – 5105 mm) Bay Widths 12’ 4” (3759 mm) 11’ 0” (3353 mm) N/A
HEIGHT 16’ 9” – 18’ 0” (5105 – 5486 mm) Bay widths 12’ 4” (3759 mm) 11’ 8” (3356 mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
WIDTH 27’ 4” Rails (8331mm) (Standard) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
WIDTH 30’ 4” Rails (9246mm) (OBD) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
WIDTH 25’ 4” Rails (7722mm) (Optional) 15’ (4572mm) 14’ (4267mm) 18’ (5486mm)
OPTIONS PREFFERED MINIMUM MAXIMUM
LENGTH 25’ 4” Rails (7722mm) (Optional) 28’ (8534mm) 25’ 8” (7823mm) N/A
LENGTH 27’ 4” Rails (8331mm) No Dryer 30’ (9144mm) 27’ 8” (8432mm) N/A
LENGTH 27’ 4” Rails (8331mm) Razor and Dryer w/Covers 42’ (12802mm) 31’ 4” (9550mm) N/A
LENGTH 30’ 4” Rails w/On-Board Dryer (9246mm) 42’ (12802mm) 31’ 4” (9550mm) N/A

14’ 0” – 16’ 9” (4267 – 5105 mm) Bay Widths


Preferred Height:  12’ 4” (3759 mm)

Minimum Height: 11’ 0” (3353 mm)

Maximum Height:  N/A

16’ 9” – 18’ 0” (5105 – 5486 mm) Bay widths


Preferred Height:  12’ 4” (3759 mm)

Minimum Height: 11’ 8” (3356 mm)

Maximum Height:  N/A

27’ 4” Rails (8331mm) (Standard)


Preferred Width:  15’ (4572mm)

Minimum Width: 14’ (4267mm)

Maximum Width:  18’ (5486mm)

30’ 4” Rails (9246mm) (OBD)


Preferred Width:  15’ (4572mm)

Minimum Width: 14’ (4267mm)

Maximum Width:  18’ (5486mm)

25’ 4” Rails (7722mm) (Optional)


Preferred Width:  15’ (4572mm)

Minimum Width: 14’ (4267mm)

Maximum Width:  18’ (5486mm)

25’ 4” Rails (7722mm) (Optional)


Preferred Length:  28’ (8534mm)

Minimum Length: 25’ 8” (7823mm)

Maximum Length:  N/A

27’ 4” Rails (8331mm) No Dryer


Preferred Length:  30’ (9144mm)

Minimum Length: 27’ 8” (8432mm)

Maximum Length:  N/A

27’ 4” Rails (8331mm) Razor and Dryer w/Covers


Preferred Length:  42’ (12802mm)

Minimum Length: 31’ 4” (9550mm)

Maximum Length:  N/A

30’ 4” Rails w/On-Board Dryer (9246mm)



Preferred Length:  42’ (12802mm)

Minimum Length: 31’ 4” (9550mm)

Maximum Length:  N/A

FLOOR MOUNT

Free Standing Frame Wash Bay Dimensions

HOW TO MEASURE:

Minimum dimensions are from nearest inside obstructions entrance to exit

e.g., door tracks, counterweights, etc. Add in additional length for these items.

OPTIONS PREFFERED MINIMUM MAXIMUM
HEIGHT 27’ 4” Rails (8331mm) (Standard) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
HEIGHT 30’ 4” Rails (9246mm) (OBD) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
HEIGHT 25’ 4” Rails (7722mm) (Optional) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
WIDTH 27’ 4” Rails (8331mm) (Standard) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
WIDTH 30’ 4” Rails (9246mm) (OBD) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
WIDTH 25’ 4” Rails (7722mm) (Optional) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
LENGTH 25’ 4” Rails (7722mm) (Optional) 28’ (8534mm) 25’ 8” (7823mm) N/A
LENGTH 27’ 4” Rails (8331mm) No Dryer 30’ (9144mm) 27’ 8” (8432mm) N/A
LENGTH 27’ 4” Rails (8331mm) Razor and Dryer w/Covers 42’ (12802mm) 31’ 4” (9550mm) N/A
LENGTH 30’ 4” Rails w/On-Board Dryer (9246mm) 42’ (12802mm) 31’ 4” (9550mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
HEIGHT 27’ 4” Rails (8331mm) (Standard) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
HEIGHT 30’ 4” Rails (9246mm) (OBD) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
HEIGHT 25’ 4” Rails (7722mm) (Optional) 11’ 3” (3429 mm) 11’ 1” (3378mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
WIDTH 27’ 4” Rails (8331mm) (Standard) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
WIDTH 30’ 4” Rails (9246mm) (OBD) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
WIDTH 25’ 4” Rails (7722mm) (Optional) 14’ 4” (4369mm) 13’ 8” (4166mm) N/A
OPTIONS PREFFERED MINIMUM MAXIMUM
LENGTH 25’ 4” Rails (7722mm) (Optional) 28’ (8534mm) 25’ 8” (7823mm) N/A
LENGTH 27’ 4” Rails (8331mm) No Dryer 30’ (9144mm) 27’ 8” (8432mm) N/A
LENGTH 27’ 4” Rails (8331mm) Razor and Dryer w/Covers 42’ (12802mm) 31’ 4” (9550mm) N/A
LENGTH 30’ 4” Rails w/On-Board Dryer (9246mm) 42’ (12802mm) 31’ 4” (9550mm) N/A

27’ 4” Rails (8331mm) (Standard)


Preferred Height:  11’ 3” (3429 mm)

Minimum Height: 11’ 1” (3378mm)

Maximum Height:  N/A

30’ 4” Rails (9246mm) (OBD)


Preferred Height:  11’ 3” (3429 mm)

Minimum Height: 11’ 1” (3378mm)

Maximum Height:  N/A

25’ 4” Rails (7722mm) (Optional)


Preferred Height:  11’ 3” (3429 mm)

Minimum Height: 11’ 1” (3378mm)

Maximum Height:  N/A

27’ 4” Rails (8331mm) (Standard)


Preferred Width: 14’ 4” (4369mm)

Minimum Width: 13’ 8” (4166mm)

Maximum Width:  N/A

30’ 4” Rails (9246mm) (OBD)


Preferred Width: 14’ 4” (4369mm)

Minimum Width: 13’ 8” (4166mm)

Maximum Width: N/A

25’ 4” Rails (7722mm) (Optional)


Preferred Width: 14’ 4” (4369mm)

Minimum Width: 13’ 8” (4166mm)

Maximum Width: N/A

25’ 4” Rails (7722mm) (Optional)


Preferred Length: 28’ (8534mm)

Minimum Length: 25’ 8” (7823mm)

Maximum Length:  N/A

27’ 4” Rails (8331mm) No Dryer


Preferred Length:  30’ (9144mm)

Minimum Length: 27’ 8” (8432mm)

Maximum Length:  N/A

27’ 4” Rails (8331mm) Razor and Dryer w/Covers


Preferred Length:  42’ (12802mm)

Minimum Length: 31’ 4” (9550mm)

Maximum Length:  N/A

30’ 4” Rails w/On-Board Dryer (9246mm)



Preferred Length:  42’ (12802mm)

Minimum Length: 31’ 4” (9550mm)

Maximum Length:  N/A

UTILITY

Utility Requirements

Does not include options or other equipment requirements

Water

25 GPM @ 35 psi (94.6 l/m @ 2.4 bars) minimum at pump station

Air

100 psi @ 11 SCFM (6.89 bars @ 311 l/m) includes optional Tri-Color Foam

Electrical

208/230 VAC, 3 PH, 60 Hz (Five wire, three phase with neutral and ground)

Voltage: 208 VAC


UCC Cabinet:  23 AMPS

Razor Pump Station: 73 AMPS

Optional Cold Climate Package: 14 AMPS

Add for Each Dryer Motor:

10 HP | 27 AMPS

15 HP | 40 AMPS

Voltage: 230 VAC


UCC Cabinet: 20 AMPS

Razor Pump Station: 62 AMPS

Optional Cold Climate Package: 12 AMPS

Add for Each Dryer Motor:

10 HP | 24 AMPS

15 HP | 35 AMPS

Voltage: 380/415 (50Hz)


UCC Cabinet:  17 AMPS

Razor Pump Station: 38 AMPS

Optional Cold Climate Package: 10 AMPS

Add for Each Dryer Motor:

10 HP | 15 AMPS

15 HP | 22 AMPS

Voltage: 460


UCC Cabinet:  N/A

Razor Pump Station: 31 AMPS

Optional Cold Climate Package: N/A

Add for Each Dryer Motor:

10 HP | 12 AMPS

15 HP | 17 AMPS

Voltage: 575


UCC Cabinet: N/A AMPS

Razor Pump Station: 24.5 AMPS

Optional Cold Climate Package: N/A AMPS

Add for Each Dryer Motor:

10 HP | 9.12 AMPS

15 HP | 13.6 AMPS

Water 25 GPM @ 35 psi (94.6 l/m @ 2.4 bars) minimum at pump station
Air 100 psi @ 11 SCFM (6.89 bars @ 311 l/m) includes optional Tri-Color Foam
Electrical 208/230 VAC, 3 PH, 60 Hz (Five wire, three phase with neutral and ground)
VOLTAGE UCC CABINET RAZOR PUMP STATION OPTIONAL COLD CLIMATE PACKAGE ADD FOR EACH DRYER MOTOR
208 23 AMPS 73 AMPS 14 AMPS 10 HP | 27 AMPS 15 HP | 40 AMPS
230 20 AMPS 62 AMPS 12 AMPS 10 HP | 24 AMPS 15 HP | 35 AMPS
380/415 (50Hz) 17 AMPS 38 AMPS 10 AMPS 10 HP | 15 AMPS 15 HP | 22 AMPS
460 N/A 31 AMPS N/A 10 HP | 12 AMPS 15 HP | 17 AMPS
575 N/A 24.5 AMPS N/A 10 HP | 9.12 AMPS 15 HP | 13.6 AMPS
Water 25 GPM @ 35 psi (94.6 l/m @ 2.4 bars) minimum at pump station
Air 100 psi @ 11 SCFM (6.89 bars @ 311 l/m) includes optional Tri-Color Foam
Electrical 208/230 VAC, 3 PH, 60 Hz (Five wire, three phase with neutral and ground)
VOLTAGE UCC CABINET RAZOR PUMP STATION OPTIONAL COLD CLIMATE PACKAGE ADD FOR EACH DRYER MOTOR
208 23 AMPS 73 AMPS 14 AMPS 10 HP | 27 AMPS 15 HP | 40 AMPS
230 20 AMPS 62 AMPS 12 AMPS 10 HP | 24 AMPS 15 HP | 35 AMPS
380/415 (50HZ) 17 AMPS 38 AMPS 10 AMPS 10 HP | 15 AMPS 15 HP | 22 AMPS
460 N/A 31 AMPS N/A 10 HP | 12 AMPS 15 HP | 17 AMPS
575 N/A 24.5 AMPS N/A 10 HP | 9.12 AMPS 15 HP | 13.6 AMPS

NOTE:

Specifications Subject to Change Without Notice. The decibel level of the dryer (measured at 1.6 meters from the floor and 1 meter from the surface) is 94dB. The decibel level of the pump station measured at 1.6 meters from the floor and 1 meter from the surface) is 84dB for high pressure and 72dB for low pressure. Decibel levels are impacted by surrounding materials and conditions therefore will vary.
